Hospital
Hospitals have a more demanding on power supply. The power for hospitals allow absolutely no interruption and must be provided in a super silent way. To meet the demanding requirements, the power gensets must have excellent performance, also AMF and ATS, quick start time, low noise, low emission and high security are strictly required.

1、Working conditions
24 hours consecutive stable power output at rated power (10% overload for 1 hour permissible each 12 hours) in the following conditions.
Altitude height 1000 meters.
Humidity: 60%
Temperature lower limit -40°C, upper limit 55°C
2、Low noise
The noise level is under 70db at 1.0m distance away the gensets, so that the doctors can work in quiet, also the patients can have an undisturbed rest environment.

3、Main and necessarily protective equipments
The gensets will automatically stop and give signals in the following cases: low oil pressure, high temperature, over speed, start failure.
When the main fails, the control panel will auto start after the confirmation(0-60s adjustable). The power generator can start itself consecutively for three times. It is about 5s for the auto start, 2-3s running before loading. When the frequency and voltage reach the rated value, the control panel will give ATM a signal to automatic switch the main load to generator load; when the mains power gets back, the control panel will give the ATS a signal to automatic switch the generator load to main load after the confirmation(0-60 mins delay adjustable), the gensets will automatically stop after cooling (0-60 mins delay adjustable) and then stand by. The generator could start successfully at the rate 99%.

4、Stable performance & high reliability
Average failure interval: not less than 3000 hours
Technical parameters: steady-state voltage regulation≦±0.5%,transient voltage regulation≦±15%.steady time 1.0s. on no load: line voltage sin waveform distortion <3%,volatility <0.5%; steady-state frequency regulation≦±0.5%,transient frequency regulation≦±5%,steady time <3s,volatility≦0.5%)
Advanced diesel engine control system and excellent ECU alarming function. Self-faults diagnostic system can detect engine fault codes. Low fuel consumption.
The automatic control and ATS could satisfy the hospital’s special requirements. The machine can be connected with computer(friendly  interface, operation software in both Chinese and English) with RS232 or RS485/422 connector to realize remote control, remote signaling and telemetering automatically at unattended operation

Adopt standard design, the spare parts are compatible, convenient for maintenance.
Whole set product and turn-key solution help customer use and maintain the machine easily without much technical knowledge.
The control system could realize auto switch, auto start, auto stop and alarming.
Save cost and well envirnment protection, low consumption, superb emission index, low noise (under 70db at 1.0m distance)
