1.       Remote Control

Through connector RS485 to satisfy the remote monitoring requirement, realize remote control, remote signaling and telemetering automatically, get the real-time running parameters and status. When abnormality or serious faults occur, the machine will give the control center alarms and realize remote control.

Series connection ---with ATS, realize auto switch between the main and gensets, or between two standby gensets .

Paralleling --- Under rated power factor, two or more gensets with three phase, can be paralleled smoothly。



3. Working conditions

24 hours consecutive stable power output at rated power (10% overload for 1 hour permissible each 12 hours) in the following conditions.

Altitude height 1000 meters and below.

Humidity:60%

Temperature lower limit -40°C, upper limit 55°C

Special area could choose the other solution according to the corresponding conditions.

4、Main and necessarily protective equipments

The gensets will automatically stop and give signals in the following cases: low oil pressure, high temperature, over speed, start failure.

When the main fails, the control panel will auto start after the confirmation(0-60s adjustable). The power gensets can start itself consecutively for three times( 5s start, 2-3s running before loading). When the frequency and voltage reach the rated value, the control panel will give ATM a signal to automatically switch the main loading to gensets load; when the main power gets back, the control panel will give the ATS a signal to automatically switch the gensets loading to main load after the confirmation(0-60 mins delay adjustable), the gensets will automatically stop after cooling (0-60 mins delay adjustable) and then stand by. The gensets could start successfully at the rate 99%.



5．Stable performance & high reliability

Average failure interval: not less than 3000 hours

Technical parameters: steady-state voltage regulation≦±0.5%,transient voltage regulation≦±15%.steady time 1.0s. on no load: line voltage sin waveform distortion <3%，volatility <0.5%; steady-state frequency regulation≦±0.5%,transient frequency regulation≦±5%，steady time <3s，volatility≦0.5%）

Advanced diesel engine control system and excellent ECU alarming function. Self-faults diagnostic system can detect engine fault codes.



Superb power gensets, with low noise design, configured with auto control system, connected ATS to ensure the standby power could supply immediately once the main fails. The power supply is stable, low noise and optimized exhausting, which is compliant with the Germany TA-Luft Standard，the U.S. California Air Resources Board( CARB) standard, U.S. Environmental Protection Agency(EPA) standard and European off-highway emission standard. The automatic control and ATS could satisfy the broadcasting and television’s special requirements. The machine can be connected with computer(friendly interface, operation software in both Chinese and English) with RS232 or RS485/422 connector to realize remote control, remote signaling and telemetering automatically at unattended operation.





Adopt standard design, the spare parts are compatible, convenient for maintenance.

Whole set product and turn-key solution help customer use and maintain the machine easily without much technical knowledge.

The control system could realize auto switch, auto start, auto stop and alarming.

Save cost and well environment protection, low consumption, superb emission index, low noise (under 70db at 1.0m distance)

Compact size, some special options are provided to meet demand in the cold, tropical areas.

For bulk order, custom design and development is provided.
